Fit a Rotation with PyTorch

Fit a rotation in \(Cl(3,0)\) from point correspondences. A bivector supplies three generator coefficients, in the order \(e_{12},e_{13},e_{23}\). The planned action turns those coefficients into a length-preserving transformation; PyTorch supplies the parameter, coordinate loss, and optimizer. This is one use of differentiation through a planned operation: the training loop acts on ordinary tensors while preserving the operation's contracts.

Construct a correspondence problem

import torch
from clifra import make_algebra

torch.manual_seed(7)
algebra = make_algebra(3, 0, dtype=torch.float64)
vectors = algebra.layout((1,))
bivectors = algebra.layout((2,))
action = algebra.plan_versor_action(
    grade=2, input=vectors, parameter=bivectors, output=vectors,
)
points = torch.randn(32, 3, dtype=torch.float64)
true_generator = torch.tensor([0.6, -0.35, 0.25], dtype=torch.float64)
with torch.no_grad():
    targets = action(points, true_generator)

The single generator broadcasts across all 32 points. This is a global rotation about the origin: it has no translation, scaling, or deformation parameters. The points span three dimensions, so the correspondences constrain the rotation. A single vector would leave rotation about its own axis undetermined.

Fit the generator

generator = torch.nn.Parameter(torch.zeros(3, dtype=torch.float64))
optimizer = torch.optim.Adam([generator], lr=0.06)
initial_loss = (action(points, generator) - targets).square().mean().detach()

for step in range(240):
    optimizer.zero_grad()
    prediction = action(points, generator)
    loss = (prediction - targets).square().mean()
    loss.backward()
    optimizer.step()

Each optimizer step updates three ordinary real coefficients. Autograd differentiates the induced action with respect to them; there is no need to optimize a separate matrix and repair its orthogonality after each update. The parameterization restricts the fit to the action's geometric family.

The loss is squared Euclidean distance between vector coordinates. That is a suitable residual here because the signature is Euclidean and the point correspondences are known. It is not a general prescription to minimize a signature-sensitive quadratic form, which may be negative or vanish for a nonzero residual.

Validate the transformation

Check held-out points and a geometric invariant, rather than accepting only a falling training loss.

with torch.no_grad():
    fitted = action(points, generator)
    final_loss = (fitted - targets).square().mean()
    held_out = torch.randn(16, 3, dtype=torch.float64)
    expected = action(held_out, true_generator)
    actual = action(held_out, generator)
    assert final_loss < initial_loss * 1e-6
    torch.testing.assert_close(actual, expected, atol=2e-5, rtol=2e-5)
    torch.testing.assert_close(actual.square().sum(-1), held_out.square().sum(-1))
    torch.testing.assert_close(action(actual, -generator), held_out)

The recovered action matters more than exact recovery of the generator. Because exponential coordinates are not globally unique, large rotations can produce equivalent transformations from different coefficients. This example starts near zero to stay within a simple local regime; arbitrary initializations need not have the same optimization behavior.

A module can register both the generator and the planned action as attributes, then use ordinary model.parameters() and .to(). No additional abstraction is required for this three-parameter fit.
